Features:
Compact , light and easy to carry
Double pawl braking system
Asbestos free friction disc
Industrial power coating meet RoHS requirement
1500 cycles lifting test , meet JBT7334,EN13157, ANSI B30.16, AS1418 standards
Heat treated steel plates , gears and shaft for enhanced strength , forged hooks with safty latches and high tensile alloy steel chain
Free-wheel mechanism for quick adjustment of chain
Gear clutch device makes it easy to adjust the hook with idle load.
Parameters:
Model | VL-0.75 | VL-1 | VL-1.5 | VL-3.0 | VL-6.0 | VL-9 | |
Capacity (TON) | 0.75 | 1 | 1.5 | 3 | 6 | 9 | |
Standard Lifting Height(M) | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | |
Running test load (KN) | 11.2 | 15 | 22.5 | 45 | 75 | 112.5 | |
Effort required to lift max. load (N) | 140 | 185 | 230 | 285 | 385 | 390 | |
No. of chain strand | 1 | 1 | 1 | 1 | 2 | 3 | |
Load Chain Dia.(MM) | 6.3 | 6.3 | 7.1 | 9 | 9 | 9 | |
Net.weight(KG) | 7.5 | 7.5 | 9.5 | 16.5 | 27 | 40 | |
Extra weight meter of extra lift(kg) | 0.85 | 0.85 | 1.1 | 1.8 | 3.6 | 5.4 | |
Dimensions (MM) | A | 153 | 153 | 166 | 195 | 195 | 195 |
B | 86 | 86 | 100 | 112 | 112 | 112 | |
C | 130 | 130 | 150 | 202 | 242 | 312 | |
D | 38 | 38 | 48 | 50 | 65 | 81 | |
H | 295 | 295 | 335 | 450 | 550 | 660 | |
L | 315 | 315 | 365 | 365 | 365 | 365 | |
K | 27 | 27 | 36 | 38 | 48 | 54 | |
| |||||||
