Features:
Specifications: 0.25kw-2.2kw
Type: 0.25kw-2.2kw
Die-cast aluminum alloy shell, good heat dissipation;
Gear with low carbon alloy steel by carburizing quenching, low noise, high wear resistance, long service life.
Insulation class F, the maximum pressure of 1500V, strong power;
DC electromagnetic brake, brake safety. And with an external mediation brake device, easy to operate;
Lightweight, light weight, novel shape.
1.walking gear box
Triple structure
Gear material for the chromium molybdenum alloy, anti-wear bearings
CNC automatic gear machining center production, hardened surface (HRC60) after grinding treatment
Semi-grease lubrication, maintenance-free
2. reducer: shell with high tension with cast iron (FC25) manufacturing
Gear with alloy steel,
Accuracy is high, wear, impact resistance,
3.soft start device:
Start and brake are very smooth and smooth, heavy objects will not shake.
4.the motor part:
High performance, high torque, motor body easy to heat, small current, small size, strong output power, high frequency can be used.
5. electromagnetic brake:
Using DC brakes, braking force, bolts directly adjust the braking force, long life, high security, never fall off.
6.wheels
Ball mill cast steel – good elasticity of small noise
Wheel surface hardening treatment
Small diameter, height reduced
Material: 42CrMo
Surface hardening treatment
Bearing NSK
Limit switch
Machine structure:
● limit size is small, increase the effective working area
● reduce plant height, save construction costs ,Small Occupied Space
● small size, light weight,high working performance
● Easy Operation
● Safe and Reliable
● Low Operation and Maintenance Costs
Parameters:
