1. The normal travelling speed: 15m/min (dual speed 20/6 is optional)
2. Hoist electrics cubicle including low voltage transformer
3. Motor protection IP54 insulation class F
4. Push button box with emergency button
5. Rope guide for use in aggressive environment
6. Remote control is optional, Hook with safety latch
7. The hoist is made under the FEM European standard, with planetary gearbox(low noises and free maintenance).
8. The motor and gearbox are installed at the same side, help the hoist to run smoothly and increase of service life.
Parameters：
| Model | usage | volatage(v) | power(kg) | capacity(kg) | lifting speed(m/Min) | lifting height(m) | weight(kg) |
| 300-600 | single rope | 220/380 | 0.6 | 300 | 16 | 30-100 | 34 |
| double rope | 600 | 8 | |||||
| 500-1000 | single rope | 1.1 | 500 | 14 | 49 | ||
| double rope | 1000 | 7 | |||||
| 750-1500 | single rope | 1.5 | 750 | 10 | 55 | ||
| double rope | 1500 | 6 |
